EDATEC CM4 NANO incl. CM4104016

CM4 Nano is an embedded computer designed for industrial applications based on Raspberry Pi Compute Module 4 (CM4 for short). It makes full use of the structural flexibility of CM4 to solve the heat dissipation problem of CPU, wireless module and PMU. The BT antenna improves the reliability of wireless communication and provides flexible expansion capabilities.

For application scenarios that require large data storage capacity, user can use eMMC to install the operating system and store the application data, at the same time, users can use SD card to store large user data, compare to the built-in eMMC memory, SD card can offer larger capacity and its cost is more effective.
CM4 Nano provides alarm buzzer ,battery-powered real-time clock, , supports Gigabit Ethernet port with POE function, which is compatible with the official Raspberry Pi PoE HAT.
The CSI and DSI interfaces of CM4 Nano are fully compatible with Raspberry Pi4 Model B. CSI supports Raspberry Pi official 8M and 12M Pixel HQ cameras, and DSI interface supports Raspberry Pi official 7" touch display. The Standard HDMI interface can output 4K HD video.

CM4 Nano provides 2 channels USB3.0 and 1 channelUSB2.0 interfaces, and the USB2.0 interface can be used to update the system image.
CM4 Nano provides very strong expansion capabilities, supports a standard Raspberry Pi 40-pin expansion interface, and users can mechanical-easily expand a high speed equipment through on board USB3.0 Type C interface.
The system supports 8V~18V DC power input, the 40PIN socket provides 5V@2A and [email protected] output power, and supports high-power expansion modules.
The dimension of CM4 Nano PCB is 95*58mm, which is slightly larger than Pi4 Model B. The connectors come out from front and back end, a 103*62mm*5mm heat sink provides excellent cooling performance for CPU, wireless module and PMU, the whole system can work reliably in a high temperature environment.
Based on our real testing in the lab, CM4 Nano can work reliably at ambient temperature of -25~60°C.
Four M2.5 screw holes are reserved at the case bottom of CM4 Nano, which is convenient for users to install the CM4 Nano on other equipment. CM4 Nano also supports DIN rail mounting.

 with Case and without WiFi anbd BT
